Automotive

Brief explanation of the products below.

  • Frame mounting clips are designed to hold wiring or tubing to structural shapes on truck or trailer frames
  • Used to hold pipe, conduit, tubing or wires against a solid surface
  • Clamping Diameter Range: 3/16″ – 3/4″
  • Material: SAE 1050 Heat Treated Steel with Phosphate and Paint Finish
  • Download Specifications (145 KB)
  • Once this PVC coated clip is mounted, tubing and/or wiring can be added at a later time, a developed shape for ease of closing with a screwdriver or pliers.
  • Used to hold pipe, conduit, tubing or wires against a solid surface
  • Clamping Diameter Range: 1/8″ – 2″    Bolt Size Range: #10 – 1/2″
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (511 KBMb)
  • Used to hold pipe, conduit, tubing or wires against a solid surface with a PVC coating.
  • Clamping Diameter Range: 1/8″ – 1 1/16″    Bolt Size Range: #10 – 3/8″
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (330 KB)
  • A 1″ wide cushioned clamp designed to be slipped over tubes or wires and closed with a bolt at assembly with two round holes and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 1/4″ – 4″   Bolt Size Range: 1/2″
  • Clamp Materials: Galvanized Steel, Zinc Plated Steels, Stainless Steels and Aluminum
  • Cushion Materials: EPDM, Neoprene and Silicone
  • Download Specifications (427 KB)
  • A 1/2″ wide cushioned clamp designed to be slipped over tubes or wires and closed with a bolt at assembly with two round holes and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 3/16″ – 4″    Bolt Size Range: #8- 1/4″
  • Clamp Materials: Galvanized Steel, Zinc Plated Steels, Stainless Steels and Aluminum
  • Cushion Materials: EPDM, Neoprene and Silicone
  • Download Specifications (131 KB)
  • Medium duty clamp designed to be slipped over two tubes or wires of the same diameter and closed with a bolt at assembly with one round hole and one slot for ease of bolt alignment, and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 3/16″ – 1″    Bolt Size Range: #10- 1/2″
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (398 KB)
  • Medium duty clamp with PVC coating for abrasion resistance, two round holes and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 3/16″ – 4 1/16″    Bolt Size Range: 1/4″- 1/2″
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (1.08 MB)
  • Medium duty clamp with PVC coating for abrasion resistance, two round holes and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 1/8″ – 1″    Size Range: #8, #10
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (260 KB)
  • Light duty clamp with flared edges and PVC coating for abrasion resistance, one round hole and one slot for ease of bolt alignment, and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 1/8″ – 1 9/16″    Bolt Size Range: 1/4″ – 3/8″
  • Materials: Galvanized Steel, Zinc Plated Steel and Stainless Steel
  • Download Specifications (387 KB)
  • Light duty clamp with flared edges for abrasion resistance, one round hole and one slot for ease of bolt alignment, and a developed shape for proper closing furnished open.
  • Clamping Diameter Range: 3/16″ – 1 5/8″    Bolt Size Range: 1/4″ – 3/8″
  • Download Specifications (364 KB)
